Rigol RSA3000 Series for Real-Time RF Testing and EMI Analysis

The Rigol RSA3000 Series Real-Time Spectrum Analyzer is a high-performance RF testing instrument designed for real-time spectrum analysis, sweep spectrum analysis, EMI pre-compliance testing, and wireless communication measurements. Built for modern electronics laboratories, manufacturing facilities, research centers, and educational institutions, the RSA3000 Series delivers accurate RF measurements, advanced signal analysis, and powerful troubleshooting capabilities.

With a frequency range from 9 kHz to 3.2 GHz, the RSA3000 Series is ideal for RF signal analysis, antenna testing, EMI diagnostics, IoT device development, wireless communication systems, and production testing. Models with the “-TG” suffix include a built-in tracking generator for advanced RF component testing and network analysis.

Built-In Vector Network Analysis (VNA) Mode

The RSA3000 Series features a built-in Vector Network Analysis (VNA) mode that supports S11, S21, and Distance-to-Fault (DTF) measurements for RF components and circuit networks. Engineers can accurately analyze antennas, RF filters, cables, amplifiers, and passive RF devices using advanced network analysis tools.

The analyzer supports Smith Chart, Polar Chart, and other graphical display formats for detailed impedance and network characteristic analysis. (*Available on N-models only)

VNA Measurement Applications

• S11 return loss testing
• S21 insertion loss analysis
• Distance-to-Fault (DTF) measurements
• Antenna impedance testing
• RF cable and filter characterization
• Passive RF component analysis

EMI Pre-Compliance Testing with Built-In EMI Software

The Rigol RSA3000 includes built-in EMI pre-compliance testing software combined with CISPR-compliant EMI filters and detectors. This advanced EMI analysis capability allows engineers to identify conducted and radiated emission issues before formal certification testing.

By detecting EMI problems early during product development, the RSA3000 Series helps reduce compliance testing costs, improve product reliability, and accelerate product certification and time-to-market.

EMI Testing Benefits

• Conducted EMI testing
• Radiated EMI testing
• CISPR-compliant EMI filters
• Faster EMI troubleshooting
• Reduced compliance laboratory costs
• Improved product certification efficiency

Advanced Signal Triggering and Monitoring with FMT Mode

The RSA3000 Series supports Frequency Mask Trigger (FMT) mode, a powerful triggering function designed specifically for real-time spectrum analyzers. Engineers can quickly create custom frequency mask templates and automatically trigger on signals that match predefined conditions.

FMT mode helps users detect intermittent interference, sporadic RF anomalies, and unexpected signal behavior within monitored frequency ranges.

Benefits of FMT Trigger Mode

• Detect transient RF anomalies
• Monitor intermittent interference signals
• Improve real-time RF signal monitoring
• Trigger on custom signal conditions
• Enhance RF troubleshooting accuracy

Ultra-Low 1 Hz Resolution Bandwidth for Precise RF Signal Analysis

The RSA3000 Series features an ultra-low Resolution Bandwidth (RBW) as low as 1 Hz, enabling engineers to distinguish weak and closely spaced RF signals with high accuracy. This advanced RF analysis capability improves signal visibility and delivers highly detailed spectrum measurements.

The 1 Hz RBW is ideal for harmonic analysis, adjacent channel testing, low-noise measurements, and wireless communication signal analysis.

Applications of 1 Hz RBW

• RF signal analysis
• Harmonic and interference detection
• Adjacent channel measurements
• Wireless communication testing
• Low-level signal analysis
• Precision spectrum measurements

Exceptional Sensitivity with DANL as Low as -161 dBm

With the optional preamplifier enabled, the Rigol RSA3000 Series achieves a Displayed Average Noise Level (DANL) as low as -161 dBm. This ultra-low noise floor enables engineers to detect weak RF signals, hidden harmonics, and low-level interference sources with greater accuracy.

The high sensitivity improves troubleshooting performance in both swept spectrum analysis and real-time spectrum analysis modes.

Advantages of Ultra-Low DANL

• Detect low-power RF signals easily
• Improve harmonic and interference analysis
• Identify hidden RF noise sources
• Enhance RF troubleshooting performance
• Increase signal measurement accuracy

Multiple Connectivity Interfaces for Flexible Operation

The RSA3000 Series includes multiple connectivity interfaces to improve instrument integration and remote operation. Engineers can connect the analyzer to external monitors through the HDMI interface for enhanced visualization and improved signal analysis.

The built-in Web Control function allows users to remotely control the instrument directly through a web browser using the device IP address, improving remote access and testing flexibility.

Connectivity Features

• HDMI output for external monitor connection
• Remote Web Control functionality
• LAN connectivity for network integration
• Improved remote testing capability
• Flexible laboratory and production setup

Large 10.1-Inch Multi-Touch Screen for Easy Operation

The Rigol RSA3000 Series features a responsive 10.1-inch multi-touch capacitive touchscreen designed for faster setup and improved user interaction. The intuitive interface supports gestures such as dragging, zooming, expanding, and waveform navigation for a more efficient RF testing experience.

The advanced touchscreen design helps engineers simplify complex measurements and improve daily workflow efficiency.

Multi-Touch Screen Features

• 10.1-inch capacitive touchscreen
• Gesture-based waveform control
• Fast setup and navigation
• Improved user interaction and workflow
• Enhanced RF testing efficiency

Key Features of Rigol RSA3000 Series

• Real-time spectrum analyzer with sweep spectrum analysis
• Frequency range from 9 kHz to 3.2 GHz
• Built-in Vector Network Analysis (VNA) mode
• S11, S21, and DTF measurement support
• EMI pre-compliance testing software
• Frequency Mask Trigger (FMT) mode
• Ultra-low 1 Hz Resolution Bandwidth (RBW)
• DANL as low as -161 dBm with optional preamplifier
• HDMI output and remote Web Control support
• 10.1-inch multi-touch capacitive display
• Tracking generator models available (“-TG”)
• Ideal for RF testing, EMI analysis, antenna testing, IoT devices, wireless communication systems, and educational applications
