Electrostatic Discharge Simulator (ESS series) ESD Simulator ESS-PS1 & GT-31S
Electrostatic Discharge Simulator (ESS series) ESD Simulator ESS-PS1 & GT-31S
| Output voltage | 0.2kV～30.0kV |
| Polarity | Positive / negative |
| Repetition cycle | 0.05s ～ 600s |
| Discharge number of times | 1 – 60,000 times, continuous |
| Discharge mode | Contact discharge / Air discharge |
| Test mode | IEC standard test mode Manual test mode Sequence test mode |
| Trigger mode | Gun trigger / External trigger |
| Discharge detection | present |
| Pre-check function | present |
| CR-cup check | IEC & ISO detection |
| Operation panel | Color LCD touch panel (resistive film type) |
| Language | English / Japanese |
| External Control | Optical connector connection for PC communication |
| Power Supply | AC100V ～ 240V / battery |
| Dimensions | Power Supply Unit: (W)180×(H)124×(D)292mm Gun: (W)90×(H)236.2×(D)285.4mm * protrusions excluded |
| Weight | Power Supply Unit: 3kg (excluding AC adapter) Gun: 1.2kg (cables included/connector excluded) |
| Gun Holder | Included in the packag |
Description
This tester simulates the electrostatic discharge phenomenon from a charged human body and evaluates the resistance of electronic devices to electrostatic discharge.
Electrostatic discharge occurs when a charged human body approaches an operation panel, button switches, or housing of electronic devices. It generates a high-voltage, highfrequency noise which can cause malfunctions in the electronic devices.
Electrostatic testing reproducing noise caused by electrostatic discharge is one of the essential immunity tests to prevent troubles caused by noise in the market.
● IEC 61000-4-2 / ISO 10605 Standards compliance.
● Touch panel operation discharge gun improves operability.
● Portable battery unit offer convenient testing for large equipment.
● Pre-check function for simple pre-start inspection to ensure correct testing.
● One-touch replacement of CR unit.
